The 2026 Ford F-150 retains familiar exterior footprints and cargo box geometry from recent model years while continuing with multiple cab and bed configurations.
Body width (no mirrors): 79.9 in
Width (mirrors out / folded): 95.7 in / 83.6 in
Bed lengths (floor): 67.1 in (5.5 ft), 78.9 in (6.5 ft), 97.6 in (8.0 ft)
Width between wheelhouses: ~50.6 in
Bed depth (height): ~21.4 in
Typical wheelbase range: ~122.0–157.2 in (by cab/bed)
Typical overall length range: ~209.1–243.5 in (by cab/bed)
Typical height range: ~75–79 in (by trim/suspension)
Expect detailed numbers by trim and cab/bed combo to align closely with the established 14th-generation benchmarks.
2025 Ford F-150 Dimensions
For 2025, the F-150 continues the 14th-generation package with consistent body width and cargo box dimensions across most trims.
Body width (no mirrors): 79.9 in
Width (mirrors out / folded): 95.7 in / 83.6 in
Bed lengths (floor): 67.1 / 78.9 / 97.6 in
Width between wheelhouses: ~50.6 in
Bed depth (height): ~21.4 in
Wheelbase examples: ~122.0 in (Regular Cab, short), ~145.4 in (SuperCrew, 5.5 ft), up to ~157.2 in
Overall length range: ~209.1–243.5 in
Typical height range: ~75–79 in (by trim/suspension)
Mirror widths and box geometry are consistent; overall length and height vary by cab, bed, and suspension setup.
2024 Ford F-150 Dimensions
The 2024 F-150 shares the same core body and box measurements as its 2025 sibling, with variations dependent on configuration.
Body width (no mirrors): 79.9 in
Width (mirrors out / folded): 95.7 in / 83.6 in
Bed lengths (floor): 67.1 / 78.9 / 97.6 in
Width between wheelhouses: ~50.6 in
Bed depth (height): 21.4 in
Wheelbase examples: ~122.0–157.2 in
Overall length range: ~209.1–243.5 in
Typical height range: ~75–79 in
The consistent width baseline keeps the truck manageable in garages and lanes while offering multiple bed options for payload needs.
2023 Ford F-150 Dimensions
The 2023 F-150 maintains the footprint established by the 2021 redesign, with repeatable box dimensions and body widths across trims.
Body width (no mirrors): 79.9 in
Width (mirrors out / folded): 95.7 in / 83.6 in
Bed lengths (floor): 67.1 / 78.9 / 97.6 in
Width between wheelhouses: 50.6 in
Bed depth (height): 21.4 in
Wheelbase examples: ~122.0–157.2 in (by cab/bed)
Overall length range: ~209.1–243.5 in
Typical height range: ~75–79 in
Cab and box choices drive total length and wheelbase; the cargo box remains sized to carry 4×8 materials between the wheelhouses.
2022 Ford F-150 Dimensions
The 2022 F-150 (early 14th-generation) shows the same foundational body width and cargo box geometry, with overall size depending on cab and bed.
Body width (no mirrors): 79.9 in
Width (mirrors out / folded): ~95.7 in / ~83.6 in
Bed lengths (floor): 67.1 / 78.9 / 97.6 in
Width between wheelhouses: ~50.6 in
Bed depth (height): ~21.4 in
Example spec (XL Regular Cab 6.5-ft box): 209.1 in length, 75.6 in height, ~122.0 in wheelbase
Overall length range (family): ~209.1–243.5 in
Typical height range: ~75–79 in
Variations by trim, axle, and suspension affect stance and height, but core cargo box dimensions are consistent.
Ford F-150 Dimensions: What They Mean on the Road
These dimensional numbers show how adaptable the F-150 is for daily driving and work use. Widths under 80 inches, excluding mirrors, make it manageable on narrow streets and in standard garages. When the mirrors are extended, the truck gains extra visibility, and folding them helps reclaim space. Length and wheelbase options allow drivers to choose between easier maneuvering or maximum cargo capacity depending on their priorities.
Height figures reflect cab design, suspension setup, and trim differences. Trucks with off-road packages or upgraded suspensions usually sit taller. Across every model year, Ford keeps the body width consistent while adjusting length and height options to fit different lifestyles and uses.
When choosing an F-150, consider how much bed space you actually need compared to where you drive most often. Around Spokane and the Cascades corridor, a shorter cab and bed setup can make city parking and daily driving easier. If you tow trailers or need more cargo length, the 6.5- or 8-foot bed options provide the space you need, but the overall length requires more room in driveways and garages.
Width (79.9 in body): plan mirror positions for parking garages, trailheads, and job sites.
Length and wheelbase: determine turning radius and how easily you can park in tighter areas.
Cab height and ride height: make sure there is enough clearance for garages and hilly driveways.
